FEATURES:
-
Quick installation, simple and flexible, space-saving£»
-
The tube fitting comes in a wide variety of models to meet all your needs in pneumatic piping£»
-
Even after installation, the direction of tubing can be changed freely £»
-
The release ring adopts the ellipse design to make it more convenient and labor-saving for disconnection£»
-
All taper pipe threads are pre-coated with Teflon with fine seal performance£»
-
Apart from ø 16,all EPC & APC models are equipped with the internal hexagonal holes. It is easy for them to be mounted in the narrow places. |
|
Specifications:
|
Fluid Type |
Air, Vacuum |
|
Operating Pressure |
0¡«10.2kgf/cm2(0-1.0Mpa) |
|
Negative Pressure |
-750mmHg(10Torr) |
| Max. pressure |
15.3kgf/m2(1.5MPa) |
|
Operating Temperature Range |
0¡«60¡æ |
|
Tube Material |
Nylon and Polyurethane | |
Product Code System:
¢ÙSERIES NO£º SERIES E IN BLACK COLOR£¬ SERIES A IN GRAY
¢ÚMODEL TYPE
¢ÛTUBE OUTER DIA.
|
Metric Size |
Inch Size |
|
Code |
4 |
6 |
8 |
10 |
12 |
16 |
5/32 |
3/16 |
1/4 |
5/16 |
3/8 |
1/2 |
|
Dia. |
ø4 |
ø6 |
ø8 |
ø10 |
ø12 |
ø16 |
ø5/32 |
ø3/16 |
ø1/4 |
ø5/16 |
ø3/8 |
ø1/2 | |
¢ÜTHREAD TYPE & SIZE
|
Metric Size |
|
Code |
M5 |
M6 |
M8 |
M10 |
M12 |
M12A |
M14 |
M16 |
M20 |
|
Size |
M5¡Á0.8 |
M6¡Á1 |
M8¡Á1 |
M10¡Á1 |
M12¡Á1.25 |
M12¡Á1.5 |
M14¡Á1.5 |
M16¡Á1.5 |
M20¡Á1.5 |
¡¡
| ¡¡ |
55¡ãTaper Pipe Thread (PT) |
¡¡ |
G-Thread |
| Code |
01 |
02 |
03 |
04 |
06 |
Code |
G01 |
G02 |
G03 |
G04 |
G06 |
| Size |
R1/8 |
R1/4 |
R3/8 |
R1/2 |
R3/4 |
Size |
G1/8 |
G1/4 |
G3/8 |
G1/2 |
G3/4 |
¡¡
|
UNF |
American Standard Taper Pipe Thread (NPT) |
|
Code |
U10 |
N01 |
N02 |
N03 |
N04 |
N06 |
|
Size |
10-32UNF |
NPT1/8 |
NPT1/4 |
NPT3/8 |
NPT1/2 |
NPT3/4 | | |
|
|
