Quick Connecting Tube Fitting & Accessories     F.R.L.Equipment     3/2 Way Solenoid Valve / Air     5/2 & 5/3 Way Solenoid Valve     5/2 & 5/3 Way Air Control Valve     Manifold     Solenoid Coil     Coil Socket     2/2 Way Solenoid Valve     Cylinder   3V2 Series 3/2 WAY SOLENOID VALVE / AIR SIGN Specification for Type 3V 2 10 06 NO AC110V ┯ │ ┯ │ ┯ │ ┯ │ ┯ │ ┯ │   Specification code: 3V: 3/2 Way Solenoid Valve Series code: 2:200 Series Coil and position: 10:Single head double position 20:Double head double position Adapter diameter: 06:1/8" 08:1/4" Start habitus: NC:Normally closed NO:Normally open     Standard voltage: DC12V DC24V AC24V 50/60Hz AC110 50/60Hz AC220 50/60Hz AC380 50/60Hz Specification Item 3V210-06 3V220-06 3V210-08 3V220-08 Medium Air( diameter 40mm filter net) Action mean Inside guide style Adapter diameter Inlet=outlet=release=1/8" Inlet=outlet=1/4" Circumstances temp -10~+60℃ Gas temp 5~60℃ Effective section area 14mm2(CV=0.78) 16mm2(CV=0.78) Lubrication no needed Pressure applied 1.5-9.0kgf/cm2 Max. pressure withstand 13.5kgf/cm2 Power consumption AC:4.0VA DC:3.0W Degree of protection IP65(DIN40050) Wiring mean Terminal Max. operation frequency 10 times per second Isolation property F Voltage range ±10% Min. excitation time 0.05/s Sign:3V210-08(06) 3V220-08(06)
