Quick Connecting Tube Fitting & Accessories     F.R.L.Equipment     3/2 Way Solenoid Valve / Air     5/2 & 5/3 Way Solenoid Valve     5/2 & 5/3 Way Air Control Valve     Manifold     Solenoid Coil     Coil Socket     2/2 Way Solenoid Valve     Cylinder   3V3 Series 3/2 WAY SOLENOID VALVE    SIGN Specification for Type 3V 3 10 06 NO AC110V ┯ │ ┯ │ ┯ │ ┯ │ ┯ │ ┯ │    Specification code: 3V: 3/2 Way Solenoid Valve Series code: 3:300 Series Coil and position: 10:Single head double position 20:Double head double position Adapter diameter: 06:1/8" 08:1/4"  Start habitus: NC:Normally closed NO:Normally open     Standard voltage: DC12V DC24V AC24V 50/60Hz AC110 50/60Hz AC220 50/60Hz AC380 50/60Hz Specification Item 3V310-08 3V320-08 3V310-10 3V320-10 Medium Air( diameter 40mm filter net) Action mean Inside guide style Adapter diameter Inlet=outlet=release=1/4" Inlet=outlet=3/8" Circumstances temp -10~+60℃ Gas temp 5~60℃ Effective section area 25mm2(CV=0.78) 30mm2(CV=0.78) Lubrication no needed Pressure applied 1.5-9.0kgf/cm2 Max. pressure withstand 13.5kgf/cm2 Power consumption AC:4.0VA DC:3.0W Degree of protection IP65(DIN4005) Wiring mean Terminal Max. operation frequency 10 times per second Isolation property F Voltage range ±10% Min. excitation time 0.05/s Sign:3V310-10(08) 3V320-10(08)
