轴承型号
Bearing NO. |
外形尺寸(mm)
Shape Dimension(mm) |
基本额定负荷(KN)
basic Load Rating(KN) |
极限转速
(转/分)
Max Speed(rpm) |
主要尺寸(mm)
Principal Dimension(mm) |
重量
(kg)
Weight (kg) |
|
Bore
d |
Outer Diameter
D |
Width
B |
Radius
r min |
Dynamic
Cr |
Static
Cor |
脂润滑
Grease |
油润滑
Oil |
D1
max |
a
max |
b max |
r0 max |
D2 max |
f
max |
r 1
min |
|
mm |
inch |
mm |
inch |
mm |
inch |
mm |
inch |
|
6000N Series |
|
6003N
6004N
6005N
6006N
6007N
6008N
6009N
6010N |
17
20
25
30
35
40
45
50 |
.6693
.7874
.9843
1.1811
1.3780
1.5748
1.7717
1.9685 |
35
42
47
55
62
68
75
80 |
1.3780
1.6535
1.8504
2.1654
2.4409
2.6772
2.9528
3.1496 |
10
12
12
13
14
15
16
16 |
.3937
.4724
.4724
.5118
.5512
.5906
.6299
.6299 |
0.3
0.6
0.6
1.0
1.0
1.0
1.0
1.0 |
.0118
.0236
.0236
.0394
.0394
.0394
.0394
.0394 |
6.00
9.38
10.10
10.18
12.47
13.10
16.22
16.94 |
3.25
5.02
5.85
6.91
8.66
9.45
11.96
12.95 |
17000
15000
13000
10000
9000
8500
8000
7000 |
22000
19000
17000
14000
12000
11000
10000
9000 |
33.17
39.75
44.60
52.60
59.61
64.82
71.8376.81 |
2.06
2.06
2.06
2.08
2.08
2.49
2.49
2.49 |
1.65
1.651.65
1.652.2
2.2
2.2
2.2 |
0.4
0.4
0.4
0.4
0.6
0.6
0.6
0.6 |
39.7
46.3
52.7
60.7
67.7
74.6
81.6
86.6 |
1.12
1.12
1.12
1.12
1.7
1.7
1.7
1.7 |
0.3
0.5
0.5
0.5
0.5
0.5
0.5
0.5 |
0.041
0.071
0.084
0.120
0.162
0.199
0.247
0.272 |
|
6200N Series |
|
6203N
6204N
6205N
6206N
6207N
6208N
6209N
6210N |
17
20
25
30
35
40
45
50 |
.6693
.7874
.9843
1.1811
1.3780
1.5748
1.7717
1.9685 |
40
47
52
62
72
80
85
90 |
1.5748
1.8504
2.0472
2.4409
2.8346
3.1496
3.3465
3.5433 |
12
14
15
16
17
18
19
20 |
.4724
.5512
.5906
.6299
6693
.7086
.7480
.7874 |
0.6
1.0
1.0
1.0
1.1
1.1
1.1
1.1 |
.0236
.0394
.0394
.0394
.0433
.0433
.0433
.0433 |
9.58
9.88
10.78
14.97
19.75
22.71
24.36
26.98 |
4.47
6.20
6.98
10.04
13.67
15.94
17.71
19.84 |
16000
14000
12000
9500
8500
8000
7000
6700 |
20000
18000
16000
13000
11000
10000
9000
8500 |
38.10
44.60
49.73
59.61
68.81
76.81
81.81
86.79 |
2.06
2.46
2.46
3.283.28
3.28
3.28
3.28 |
1.65
1.651.65
2.2
2.2
2.2
2.2
3.0 |
0.4
0.4
0.4
0.6
0.6
0.6
0.6
0.6 |
44.6
52.7
57.9
67.7
78.6
86.6
91.6
96.5 |
1.12
1.12
1.12
1.7
1.7
1.7
1.7
2.46 |
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5 |
0.068
0.110
0.132
0.206
0.298
0.377
0.409
0.471 |
|
6300N Series |
|
6302N
6303N
6304N
6305N
6306N
6307N
6308N
6309N
6310N |
15
17
20
25
30
35
40
45
50 |
.5906
.6693
.7874
.9843
1.1811
1.3780
1.5748
1.7717
1.9685 |
42
47
52
62
72
80
90
100
110 |
1.6536
1.8504
2.0472
2.4409
2.8346
3.1496
3.5433
3.9370
4.3307 |
13
14
15
17
19
21
23
25
27 |
.5118
.5512
.5906
.6693
.7480
.8268
.9056
.9843
1.0630 |
1.0
1.0
1.1
1.1
1.1
1.5
1.5
1.5
2.0 |
.0394
.0394
.0433
.0433
.0433
.0591
.0591
.0591
.0788 |
8.80
10.45
12.26
17.22
20.77
25.66
31.35
40.66
47.58 |
5.43
6.56
7.81
11.39
14.17
17.92
22.38
30.00
35.71 |
16000
15000
13000
10000
9000
8000
7000
6300
6000 |
20000
19000
17000
14000
12000
10000
9000
7500
7000 |
39.75
44.60
49.73
59.61
68.81
76.81
86.79
96.80
106.81 |
2.06
2.46
2.46
3.283.28
3.28
3.28
3.28
3.28 |
1.65
1.65
1.65
2.2
2.2
2.2
3.0
3.0
3.0 |
0.4
0.4
0.4
0.6
0.6
0.6
0.6
0.6
0.6 |
46.3
52.7
57.9
67.7
78.6
86.6
96.5
10.6.5
116.6 |
1.12
1.12
1.12
1.7
1.7
1.7
2.46
2.46
2.46 |
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5 |
0.084
0.119
0.148
0.239
0.370
0.468
0.647
0.833
1.090 |
